Airquest RGF Rooftop Units

Description

Airquest RGF Rooftop Units

3, 4, 5 AND 6 TON UNITS
SINGLE-PACKAGED ROOFTOP
GAS HEAT/ELECTRIC COOLING WITH R-454B REFRIGERANT

RGF units are single-packaged electric cooling, gas heating rooftops. All units are pre-wired and pre-charged with new, low global warming potential R-454B refrigerant. R-454B represents a 75% reduction in refrigerant GWP over legacy R-410A models. All units are factory tested in both heating and cooling modes. 3-5 ton models use single stage cooling capacity control. 6 ton models use two-stage cooling capacity control.

PERFORMANCE FEATURES

• R-454B refrigerant.
• Single-stage cooling capacity 036-060 models, two-stage on 072 models.
• SEER2s up to 13.4.
• IEERs up to 15.5.
• New: A2L Leak Detection and Dissipation system factory installed standard.
• Leak system ensures unit and occupant safety during operation and includes an alarm relay for optional use.
• Onboard recallable leak detection history for easier troubleshooting and service.
• Direct Drive: X-Vane Indoor fan system uses Vane Axial fan design and electronically commutated motor.
• New Unit Control Board with intuitive quick fan speed adjustment.
• Meets and exceeds ASHRAE 90.1 energy efficiency levels.
• Sound levels as low as 79 dB.
• Exclusive non-corrosive composite condensate pans in accordance with ASHRAE 62 Standard, sloping design; side or center drain.
• AFUE Gas efficiencies up to 81%.
• Induced draft combustion design.
• Redundant gas valve, with up to two stages of heating.
• Pre-painted exterior panels and primer-coated interior panels tested to 500 hours salt spray protection.
• Fixed refrigerant metering system on 036-060 models, TXV on 072 size models.

• Fully insulated cabinet.
• Exclusive IGC solid-state control for on-board diagnostics with LED error code designation, burner control logic and energy saving indoor fan motor delay.

• Dedicated 3-5 ton “Ultra Low NOx” models available that meet California Air Quality Management NOx requirement. Models of 14 nanogram/joule are avail-able. Ultra Low NOx models include stainless steel heat exchangers.
• Standard cooling operating range up to 115°F (46°C), and down to 40°F (4°C). Low Ambient allows cooling operation down to –20°F (–29°C).
• Rated in accordance with AHRI Standards 210/240 (036-060 sizes) and 340/360 (072 size).
• Designed in accordance with Underwriters Laboratories Standard UL 60335-1 and UL 60335-2-40.
• Listed by UL and UL-Canada.

MAINTENANCE FEATURES

• Access panels with easy grip handles.
• Innovative, easy starting, no-strip screw feature o n unit access panels.
• Two-inch disposable return air filters.
• Tool-less filter access door.
• New central terminal board facilitating simple safety circuit troubleshooting and simplified control box arrangement.

INSTALLATION FEATURES

• Field Convertible from vertical to horizontal airflow o n all models. No special kit required.
• Provisions for thru-the-bottom power entry capability.
• Single point gas and electric connections.
• Full perimeter base rail with built-in rigging adapter s and fork truck slots.
• Two stage cooling thermostats required on 072 size to help provide energy saving and comfort benefits.

RELIABILITY FEATURES

• A2L Leak Detection and Dissipation system standard.
• Scroll compressors with internal line-break overload protection.
• 24-volt control circuit protected with resettable circuit breaker.
• Permanently lubricated evaporator-fan motor.
• Totally enclosed condenser motors with permanent ly lubricated bearings.
• Low pressure switch and high-pressure switch protection.
• Exclusive IGC anti-cycle protection for gas heat operation.
• Solid-state electronic direct spark ignition system.
• Flame roll-out safety protector.
• Liquid line filter drier on each circuit.

STANDARD WARRANTY

• 10-year heat exchanger: Aluminized.
• 15-year heat exchanger: Stainless Steel.
• 10-year heat exchanger: Ultra Low NOx.
• 5-year compressor parts.
• 1-year parts.

AVAILABLE OPTIONS AND ACCESSORIES

• Patented Hot Gas Re-Heat adaptive dehumidification system. This option also includes Low Ambient controls.
• Through the base connections for gas and electric available as an accessory.
• Stainless steel gas heat exchanger includes tubes, vestibule plate and collector box. Stainless Steel Heat Ex-changers are standard on all Ultra Low NOx models.
• Disconnect and convenience outlet options.
• Medium and High static motor options.
• Smoke detector, supply and/or return air.
• Corrosion resistant options for evaporator and condenser coils.
• CO2 Sensor.
• Phase Monitor Protection.
• 2-Position Damper.
• Hinged access panels.
• Integrated economizer system. Low and Ultra Lo w Leak versions.
• Condensate overflow switch.
For a complete list of options and accessories, refer to the Specification Sheets/Catalog for this unit.
